Scratch and Dent, Extreme Root Grapple Rake Attachment | 60" Crafted

Product Overview

* Scratch and Dent items are not eligible for returns or warranty claims. *
* Scratch and Dent Deal – item may have cosmetic damage and/or missing hardware *

This extreme-duty rake-style grapple transports heavy rocks, logs, brush, and debris and has an extra wide 50″ opening height for lifting large, bulky objects. Equipped with twin hydraulic 3,000 PSI cylinders, it provides powerful lifting capabilities for the most demanding tasks. This attachment fits any skid steer with a universal skid steer mounting system and will hold anything your loader can lift. Built with durable steel, it has heat-treated, replaceable steel teeth for a rock-solid grip and comes with greaseable pins, bushings, hoses, and couplers.

These Extreme Root Grapple rake’s have a maximum loader rated operating capacity of 3,500 lb.

Note: This hose kit only includes the feed/return hoses. Contact Titan support to request other hoses.

Specifications

Specifications

Overall Width

60-in.

Opening Height

50-in.

Side Thickness

0.5-in.

Teeth Length

35.5-in.

Teeth Thickness

0.5-in.

Material

Finish

Powder-Coated Black

Material

Durable Steel

Weight

Min Loader Rated Operating Capacity

1,644 lb.

Max Loader Rated Operating Capacity

3,500 lb.

Product Weight

815 lb.

Details

• ‍Universal Skid Steer Style Hookup
• ‍Twin 3,000 PSI cylinders
• ‍Replaceable bucket teeth
• ‍Greaseable pins and bushings
• ‍Hoses and flat-faced couplers included
• NOTE: This hose kit only includes the feed/return hoses. Contact Titan support to request other hoses.

REPLACEMENT PARTS

• 113119 – Hydraulic Hose Kit
• 125049 – 3 Pack Replacement LW80 OWM Bucket Tooth Kit

View Product Manual
